Solid Exit 2 Emergency Exit Light Y3192WM148

Self-contained Escap emergency exit light with 1 h super capacitor and Lumi Test self-testing with 1-sided pictogram, arrow up, 30 m viewing distance (Invidually packed TWS3192WM)

Solid Exit 2 emergency exit light is equipped with a light plate. The luminaire is designed specifically to withstand harsh conditions. It is a IP65 enclosure classed luminaire and completely dust and water proof.
Solid Exit 2 is suitable for example for industrial premises and parking halls. Escap and centrally supplied luminaires are also suitable for outdoor use.
Special attention has been paid to the design for easy installation.

1 h
icon-ce
EN 1838
EN 60598_2_22
icon-Escap
850 °C
65
icon-LED
icon-LumiTest
220-240 V 50/60 Hz AC
icon-ProtectionClassII
9003 (Signal white)
icon-Through-wiring
30 m
Product codeY3192WM148Electrical number (FI)4211197
GTIN6438045022772TARIC code94056180
Weight1,80 kgMeasurements37,10 × 18,10 × 23,20 cm
Backup (h)YesBody materialplastic
CE MarkYesColourRAL9003 (Signal white)
Electrical Installation2/3 x 2,5 mm²EN 1838Yes
EN 60598-2-22YesEscapYes
ETIM classEmergency luminaire (EC001957)Glow Wire Test of Plastic Materials (°C)850
IP ClassIP65Light SourceLED
Lumi TestYesMountingSurface, Wall
Nominal Supply Voltage220-240 V, 50/60 Hz ACPictogramright
Protection ClassIITemperature Range Min - Max (°C)-25…+35
Suitable for Through-WiringYesViewing distance30 m
Product codeY3192WM148
Electrical number (FI)4211197
GTIN6438045022772
TARIC code94056180
Weight1,80 kg
Measurements37,10 × 18,10 × 23,20 cm
Backup (h)Yes
Body materialplastic
CE MarkYes
ColourRAL9003 (Signal white)
Electrical Installation2/3 x 2,5 mm²
EN 1838Yes
EN 60598-2-22Yes
EscapYes
ETIM classEmergency luminaire (EC001957)
Glow Wire Test of Plastic Materials (°C)850
IP ClassIP65
Light SourceLED
Lumi TestYes
MountingSurface, Wall
Nominal Supply Voltage220-240 V, 50/60 Hz AC
Pictogramright
Protection ClassII
Temperature Range Min - Max (°C)-25…+35
Suitable for Through-WiringYes
Viewing distance30 m

Scale Images

Scale image

Accessories

Product codeElectrical numberDescription
TWT30014226329Solid Recess Mounting Frame TWT3001Add to cart
TWT30064148553Solid Suspension Bracket TWT3006Add to cart
TWT30044226332Solid Ceiling bracket TWT3004Add to cart
TWT30034226331Solid Flag bracket TWT3003Add to cart
TWT30024226330Solid Wall bracket TWT3002Add to cart
